TENG REVERSIBLE RATCHET COMBINATION SPANNER 8MM

TENG REVERSIBLE RATCHET COMBINATION SPANNER 8MM

Price range: $32.50 through $239.00 ex-GST

SKU: TE-600508R Categories: , ,
  • Size: 8mm
  • No of Teeth: 72
  • Reverse Direction: FlipReverseLever
  • Flexible Head: No
  • Tethering Facility: No
  • Spanner Type: Regular
  • Ratcheting: Yes
  • Material: Cr-V
  • Measuring System: Metric
  • Jaw Diameter: 17
  • JawHeight (mm): 4
  • OffSet Angle Jaw: 15
  • Ring Diameter (mm): 17
  • Ring Height (mm): 6.5
  • Offset Anglering: 15
  • Length: 140mm
  • Included In:
    • TTESP37
    • TED6512R
    • TT6508R
    • 6508RMM
    • TT6511R

Reversible Ratcheting Combination Spanner 8mm

  • A ratcheting ring and open ended spanner combined with the same size at each end
  • Off set at 13° for easier use on flat surfaces
  • TengTools hip grip design on the ring end for contact with the flat side of the fastening
  • 72 teeth ratchet spanners giving a 5° increment between clicks
  • Reversible ratchet mechanism with a flip reverse lever
  • Ideal for rapid tightening and loosening of fastenings
  • Chrome vanadium satin finish
  • Designed and manufactured to DIN ISO 1711-1 and DIN 3113A
Weight 0.037 kg
Dimensions 140 × 20 × 15 mm

ImageCodeProduct NameSpecificationsPriceQuantity
TE-600517RSTENG RATCHET COMBINATION FLAT SPANNER 17MMSize: 17mm Reverse Direction: TurnOver Jaw Diameter: 37.7 JawHeight (mm): 7.2 Ring Diameter (mm): 32 Ring Height (mm): 10.6 Length: 223mm Included In: TTEX32 TT6508RS TED6512RS TT6511RS 6512RSMM 65RS12 6508RSMM WRSP12RS$53.00 ex-GST
TE-600517RTENG REVERSIBLE RATCHET COMBINATION SPANNER 17MMSize: 17mm Reverse Direction: FlipReverseLever Jaw Diameter: 36 JawHeight (mm): 7.2 Ring Diameter (mm): 32 Ring Height (mm): 10.3 Length: 226mm Included In: 6510RMM TTESP37 TED6512R TT6508R 6508RMM TT6511R$79.00 ex-GST
TE-600516RSTENG RATCHET COMBINATION FLAT SPANNER 16MMSize: 16mm Reverse Direction: TurnOver Jaw Diameter: 34 JawHeight (mm): 6.8 Ring Diameter (mm): 30 Ring Height (mm): 10.2 Length: 202mm Included In: TED6512RS TT6511RS 6512RSMM 65RS12 WRSP12RS$48.50 ex-GST
TE-600516RTENG REVERSIBLE RATCHET COMBINATION SPANNER 16MMSize: 16mm Reverse Direction: FlipReverseLever Jaw Diameter: 33 JawHeight (mm): 6.8 Ring Diameter (mm): 30 Ring Height (mm): 9.9 Length: 208mm Included In: 6510RMM TTESP37 TED6512R TT6511R$58.00 ex-GST
TE-600515RSTENG RATCHET COMBINATION FLAT SPANNER 15MMSize: 15mm Reverse Direction: TurnOver Jaw Diameter: 32.4 JawHeight (mm): 6.5 Ring Diameter (mm): 28 Ring Height (mm): 9.7 Length: 192mm Included In: TED6512RS TT6511RS 6512RSMM 65RS12 WRSP12RS$46.00 ex-GST
TE-600515RTENG REVERSIBLE RATCHET COMBINATION SPANNER 15MMSize: 15mm Reverse Direction: FlipReverseLever Jaw Diameter: 31 JawHeight (mm): 6.5 Ring Diameter (mm): 28 Ring Height (mm): 9.4 Length: 200mm Included In: 6510RMM TTESP37 TED6512R TT6511R$53.00 ex-GST
TE-600514RTENG REVERSIBLE RATCHET COMBINATION SPANNER 14MMSize: 14mm Reverse Direction: FlipReverseLever Jaw Diameter: 29 JawHeight (mm): 6.2 Ring Diameter (mm): 27 Ring Height (mm): 9 Length: 191mm Included In: 6510RMM TTESP37 TED6512R TT6508R 6508RMM TT6511R$49.00 ex-GST
TE-600513RTENG REVERSIBLE RATCHET COMBINATION SPANNER 13MMSize: 13mm Reverse Direction: FlipReverseLever Jaw Diameter: 27 JawHeight (mm): 5.8 Ring Diameter (mm): 25 Ring Height (mm): 8.5 Length: 178mm Included In: 6510RMM TTESP37 TED6512R TT6508R 6508RMM TT6511R$46.00 ex-GST
TE-600512RTENG REVERSIBLE RATCHET COMBINATION SPANNER 12MMSize: 12mm Reverse Direction: FlipReverseLever Jaw Diameter: 25 JawHeight (mm): 5.5 Ring Diameter (mm): 23 Ring Height (mm): 8.2 Length: 172mm Included In: 6510RMM TTESP37 TED6512R TT6508R 6508RMM TT6511R$44.00 ex-GST
TE-600511RTENG REVERSIBLE RATCHET COMBINATION SPANNER 11MMSize: 11mm Reverse Direction: FlipReverseLever Jaw Diameter: 23 JawHeight (mm): 5.2 Ring Diameter (mm): 22 Ring Height (mm): 7.7 Length: 165mm Included In: 6510RMM TTESP37 TED6512R TT6508R 6508RMM TT6511R$42.00 ex-GST
TE-600510RSTENG RATCHET COMBINATION FLAT SPANNER 10MMSize: 10mm Reverse Direction: TurnOver Jaw Diameter: 22 JawHeight (mm): 4.8 Ring Diameter (mm): 20 Ring Height (mm): 7.6 Length: 131mm Included In: TTEX32 TT6508RS TED6512RS TT6511RS 6512RSMM 65RS12 6508RSMM WRSP12RS$33.00 ex-GST
TE-600510RTENG REVERSIBLE RATCHET COMBINATION SPANNER 10MMSize: 10mm Reverse Direction: FlipReverseLever Jaw Diameter: 21 JawHeight (mm): 4.8 Ring Diameter (mm): 20 Ring Height (mm): 7.3 Length: 159mm Included In: 6510RMM TTESP37 TED6512R TT6508R 6508RMM TT6511R$37.00 ex-GST
TE-600509RSTENG RATCHET COMBINATION FLAT SPANNER 9MMSize: 9mm Reverse Direction: TurnOver Jaw Diameter: 20.8 JawHeight (mm): 4.4 Ring Diameter (mm): 19 Ring Height (mm): 7.2 Length: 123mm Included In: TED6512RS 6512RSMM 65RS12 WRSP12RS$32.50 ex-GST
TE-600509RTENG REVERSIBLE RATCHET COMBINATION SPANNER 9MMSize: 9mm Reverse Direction: FlipReverseLever Jaw Diameter: 19 JawHeight (mm): 4.4 Ring Diameter (mm): 18.5 Ring Height (mm): 6.9 Length: 150mm Included In: TTESP37 TED6512R$36.00 ex-GST
TE-600508RTENG REVERSIBLE RATCHET COMBINATION SPANNER 8MMSize: 8mm Reverse Direction: FlipReverseLever Jaw Diameter: 17 JawHeight (mm): 4 Ring Diameter (mm): 17 Ring Height (mm): 6.5 Length: 140mm Included In: TTESP37 TED6512R TT6508R 6508RMM TT6511R$36.00 ex-GST
TE-600532RTENG REVERSIBLE RATCHET COMBINATION SPANNER 32MMSize: 32mm Reverse Direction: FlipReverseLever Jaw Diameter: 63 JawHeight (mm): 12.5 Ring Diameter (mm): 62.5 Ring Height (mm): 17.5 Length: 425mm$239.00 ex-GST
TE-600530RTENG REVERSIBLE RATCHET COMBINATION SPANNER 30MMSize: 30mm Reverse Direction: FlipReverseLever Jaw Diameter: 59 JawHeight (mm): 11.4 Ring Diameter (mm): 58.5 Ring Height (mm): 17 Length: 403mm$219.00 ex-GST
TE-600527RTENG REVERSIBLE RATCHET COMBINATION SPANNER 27MMSize: 27mm Reverse Direction: FlipReverseLever Jaw Diameter: 56 JawHeight (mm): 10.5 Ring Diameter (mm): 52.5 Ring Height (mm): 15.5 Length: 359mm Included In: TTESP37$181.00 ex-GST
TE-600524RTENG REVERSIBLE RATCHET COMBINATION SPANNER 24MMSize: 24mm Reverse Direction: FlipReverseLever Jaw Diameter: 52 JawHeight (mm): 9.8 Ring Diameter (mm): 43.6 Ring Height (mm): 14.5 Length: 323mm Included In: TTESP37$104.00 ex-GST
TE-600522RTENG REVERSIBLE RATCHET COMBINATION SPANNER 22MMSize: 22mm Reverse Direction: FlipReverseLeve Jaw Diameter: 45 JawHeight (mm): 9 Ring Diameter (mm): 38.4 Ring Height (mm): 13 Length: 290mm Included In: TTESP37$87.00 ex-GST
TE-600519RTENG REVERSIBLE RATCHET COMBINATION SPANNER 19MMSize: 19mm Reverse Direction: FlipReverseLever Jaw Diameter: 40 JawHeight (mm): 8.2 Ring Diameter (mm): 34 Ring Height (mm): 11.2 Length: 248mm Included In: 6510RMM TTESP37 TED6512R TT6508R 6508RMM TT6511R$64.00 ex-GST
TE-600518RTENG REVERSIBLE RATCHET COMBINATION SPANNER 18MMSize: 18mm Reverse Direction: FlipReverseLever Jaw Diameter: 38 JawHeight (mm): 7.7 Ring Diameter (mm): 33 Ring Height (mm): 10.7 Length: 237mm Included In: 6510RMM TTESP37 TED6512R TT6511R$64.00 ex-GST
